Home » Products » Wheel Balancer » Wheel Balancing Machine

Wheel Balancing Machine

Wheel Balancing Machine
Wheel Balancing Machine
Product Code : 04
Brand Name : KND EQUIPMENT
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
Product Description

Wheel Balancing Machine:

Due to our years of experience and market knowledge, we are considered as the famous trader of Premium Wheel Balancer . Made by using advance techniques, these wheel balancers are widely used to perfect balance wheels statistically & dynamically. Ideal for balancing the wheels weighing up to 65 kgs, this wheel balancer is available in different specifications. Demanded by automobile industries, Premium Wheel Balancer is offered to our customers at reasonable rates.

Approx Price: Rs 1.27 Lakh / Number

Minimum Order Quantity: 1 Number
In order to retain remarkable position in this industry, we are providing a wide array of Premium Wheel Balancer.
Features:

  • Split weight mode (spokes program)
  • Optimization program
  • Automatic Rim diameter and Rim width input
  • Automatic distance & diameter measurement: Automatic distance & rim diameter input through distance measuring rod
  • Automatic width measurement: Automatic rim width measurement.
  • Mid Centering Device: Mid centering device for positioning of wheels accurately at center of the rotor assembly
  • Optimization Program: Optimisation program helps in reduced wheel weights consumption
  • Auto Start: Automatic start with closing of wheel guard, helps in quick balancing process
  • Alloy Wheel Functions: 7 Alloy wheel (ALU) functions
  • Split weight program: Split weight program (spokes program) helps to Split the weight to be hidden behind the spokes of the alloy wheels

Specifications:

  • Suitable for Car and LCV wheels
  • Two modes of measurement - Normal Fine
  • Seven modes of Alloy wheel functions
  • Graphical user interface for live balancing
  • Unit conversion in “grams” / “ounces”
  • Rim parameter entry through wheel rotation
  • Over voltage overload protection circuit
  • Universal AC input socket
  • Self calibration
  • Automatic distance input
  • Self-checking on-line error display
  • Adjustable unbalance threshold (weight cut off)
  • High resolution (DVI input) LED Monitor / LED digital display

Other detail:

Brand: Manatec

Technical Specifications:

  • Maximum wheel weight 65 kg
  • Maximum wheel diameter 39" (990 mm)
  • Maximum wheel width 21" (533 mm)
  • Rim diameter 10" to 24" (254 mm to 610 mm)
  • Rim width 1.5" to 20" (38 mm to 508 mm)
  • Rim distance
  • By distance measuring rod 4 mm to 178 mm
  • by keypad entry 4 mm to 550 mm
  • Resolution
  • Fine mode 1 gm
  • Normal mode 5 gm
  • Minimum unbalance detection Fine, Normal
  • Rim diameter up to 16.3" 4 gm, 10 gm
  • Rim diameter above 16.3"upto 24" 9 gm, 20 gm
  • Maximum unbalance measurement 300 gm
  • Accuracy 1 gm
  • Position accuracy ± 1°
  • Balancing speed 200 RPM
  • Spin time Min. 9 sec.
  • Power Supply 230V ±10% AC, Single phase, 50Hz
  • Power 0.35HP

Additional Information:
  • Item Code: WB-VL-65-DSP-Premium-LX
Trade Information
  • Payment Terms
  • Cheque, Others
  • Main Export Market(s)
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • Main Domestic Market
  • All India
